IPD CAT C15 Inframe Kit Low Compression 17:1 SDP (LINER WITH SEALS, CREVICE TYPE)

This is for converting a C15 Acert 18:1 compression ratio to 17:1 compression ratio. (Apply for SDP)

Most commonly used  when you are taking a twin turbo C15 and converting it back to a single turbo engine. One Piece Steel piston

This Kit Contains – IPD CAT C15 Inframe Kit (Low Compression 17:1)

• 6 × Gasket Set, Single Cylinder Liner – 1183732

• 6 × Cylinder Liner 5.4 Bore – 1979322 (LINER WITH SEALS, CREVICE TYPE)

• 12 × Retainer, Piston Pin – 2502940

• 2 × Thrust Plate – 2531752

• 7 × Main Bearing, STD (Diesel) – 3178766

• 6 × Piston, IPD Steel, Welded – 3569946

• 1 × Gasket Set, In-Frame 48 – C15012NLS

• 6 × Ring Set – C15RS5

• 6 × Con Rod Bearing STD – 2613450

• 6 × Piston Pin – 5245565

• 1 × Seal-Isolation – 1685248

Key Features:

• Low Compression 17:1 CR

• Twin ACERT to Single Turbo Conversion

• Complete Inframe Rebuild Kit

"Image may be for illustrative purposes only. The kit contents shown represent the actual parts included."
